Abrites TN020 – Dashboard Calibration for Toyota and Lexus Vehicles with RH850 by Direct CAN Bus Connection (Denso)Abrites TN020 – Dashboard Calibration for Toyota and Lexus Vehicles with RH850 by Direct CAN Bus Connection (Denso)

The TN020 license is the newest solution for calibration of fully digital Denso clusters with RH850 processors, installed in Toyota and Lexus vehicles. The procedure is done in seconds via direct CAN-Bus connection to the vehicle.

Abrites TN020 – Dashboard Calibration for Toyota Functionality:

• Dashboard calibration for fully digital Denso instrument clusters with RH850 processors

Abrites TN020 – Dashboard Calibration for Toyota Supported vehicles:
Toyota and Lexus vehicles with RH850 processors, such as

• 2023 Toyota Corolla
• 2023 Toyota Corolla Cross
• 2023 Lexus LS 500
• and other models, using fully digital dashboards equipped with RH850 processors

The procedure for dashboard calibration requires the use of CB012 and CB031 cables. They are needed for establishing CAN-Bus connection to the vehicle via the Denso smart system.

Abrites TN020 – Dashboard Calibration for Toyota Required hardware and software for the procedure:

• ABRITES Vehicle Diagnostics Interface (AVDI)
• Direct CAN-BUS/LIN-BUS Connection Cable Set (CB012)
• Еxtension Cable for Direct Connecting to Toyota/Lexus Smart System with B9/BA (CB031)
• Active Annual Maintenance Subscription (AMS)

AVDI with active AMS is required to use this functionality.
