Abrites

This is a full set of ABRITES functionalities for PSA vehicles including the PN009, PN017, PN018, PN019 licenses.

The PN009 Engine Control Unit Advanced Diagnostic is a powerful license for Peugeot and Citroën vehicles with the following capabilities:

• Read/Update the Configuration Data (EDC15, EDC17(BOOT MODE), SID201, SID801, SID801A, SID802, SID803, SID803A, SID804, SID806;)
• Read/Update the flash
• Make IMMO OFF (EDC15)
• Modify/Reset service intervals (EDC15, SID201, SID801, SID801A, SID802, SID803, SID803A, SID804, SID806;)
• Read/Update the PIN codes of Engine Control Units (EDC15, SID201, SID801, SID801A, SID802, SID803, SID803A, SID804, SID806;)

Read and calibrate the mileage in the dashboard of EDC16, EDC17(BOOT MODE), SID201, SID801, SID801A, SID802, SID803, SID803A, SID804, SID806;

PN017 – BSI, Instrument Cluster Data Manager is a leader in field of Instrument cluster and BSI odometer data calibration and covers the whole range of Peugeot/ Citroën (PSA) group vehicles. It is very useful in the following situations:

• Read and calibrate the mileage stored in the instrument cluster and BSI module by OBDII
• Disable the synchronisation between the dashboard and BSI module when the calibrating the mileage in the BSI is not possible

Supported Vehicles:

Аll CAN and UDS protocol models which include almost all models produced after 2004. Support for Delphi UDS BSI 2016+ included.

Supported models for mileage calibration:

PEUGEOT

• 208 II
• 308 II
• 508 II
• 2008 II
• 3008 II
• 5008 II
• Partner III
• Traveller

CITROEN

• C3 III
• C3 Picasso
• C3 Aircross
• C4 III
• C4 Picasso II
• C4 Aircross
• C4 Cactus
• C5 Aircross
• Berlingo III
• Partner

• DS
• DS 3
• DS 3 Crossback
• DS 4
• DS 4 II
• DS 5LS
• DS 5
• DS 6
• DS 7 Crossback

Toyota

• ProAce 2016+

Lancia

• Phedra 2008+

Opel/Vauxhall

• Crossland
• Grandland
• Corsa F
• Combo
• Combo E
• Mokka
• Vivaro 2019+
• Zafira Life 2019+

Fiat

• Scudo 2022+

Ulysse 2022+

• The PN018 PIN Manager is a leader in the aftermarket solutions for key and remote control programming for the Peugeot/Citroën PSA vehicle range. Abrites is always one step ahead in terms of PIN code reading and key/remote control programming, covering the whole range of vehicles. PN018 lets you read the PIN code from all BSI types, and program keys, all by OBDII, as well as skip wait mode for models 2018+.The following BSI platforms are supported:
• Siemens K-Line
• Siemens CAN
• Johnson Controls CAN (including 2015+ with SPC microcontroller)
• Valeo CAN
• Continental UDS (including 2015+ locked)
• Valeo UDS
• Delphi CAN (Latin America)
• Delphi UDS

Supported models for PIN code reading:

PEUGEOT

• 208 II
• 308 II
• 508 II
• 2008 II
• 3008 II
• 5008 II
• Partner III

CITROËN

• C3 III
• C3 Picasso
• C3 Aircross
• C4 III
• C4 Cactus
• C4 Picasso II
• C4 Aircross
• C5 Aircross
• Berlingo III
• Partner

DS

• DS 3
• DS 3 Crossback
• DS 4
• DS 4 II
• DS 5LS
• DS 5
• DS 6
• DS 7  Crossback

Toyota

• ProAce 2016+

Lancia

• Phedra 2008+

Opel/Vauxhall

• Crossland
• Corsa F
• Combo
• Combo E
• Grandland
• Mokka
• Vivaro

Fiat

• Scudo 2022+
• Ulysse 2022+

BSI Exchange – allows you to read the whole content of the one BSI and transfer it to another one.

PN019 Advanced Coding Configuration allows you to perform changes to various coding parameters in the modules of PSA vehicles, including 2016+ models. The main functionalities are the following:

• Change current configuration parameters
• Perform retrofits in the vehicle

• Supported Models:
• The whole range of PSA vehicles, including 2016+ models, up to the latest models.

• Coding retrofitted units as though they were originally fitted to the car
• Аn AVDI interface with an active AMS is required to purchase and use this set of special functions.
