Abrites TN00F – Toyota Full Package ( TN0014, TN015, TN016, TN017 and TN019 )

Abrites TN00F – Toyota Full package contains the TN0014, TN015, TN016, TN017 and TN019 special functions.

With the TN009 you can perform reset of the ID Code Box available for ALL Toyota vehicles including the latest generation produced after 2018 and for ID Code Boxes without an external EEPROM.

The reset of the ID Code Box opens up many possibilities for those working on Toyota vehicles, mainly due to its location and the long time it takes for the vehicle to be dismantled until the ID Code Box is removed. These include:

• Key programming situations – for vehicles manufactured after 2018, where key programming requires a new set comprising an ID Code Box, Smart System and keys, users can use also second hand Smart systems (with available keys) as a plug and play solution once the ID Code Box has been reset.
• Smart system defect – in this case, just like in key programming situations all modules would have to be replaced. The reset of the ID Code Box allows you to exchange only the Smart system and the keys and both new and second hand Smart systems can be used (second hand smart systems need to have keys available)

Thе TN014 license expands the key programming capabilities of the ABRITES software for the latest generations Toyota vehicles, equipped with Tokai Rika Smart System with BA type HT-AES keys.

Functionalities:

• Spare key programming
• ALL KEYS LOST

Supported models:

• Yaris 2020+ (XP210)
• Yaris Cross 2021+ (XP210)
• Corolla Facelift 2022+ (E210)
• Corolla Cross Facelift 2022+ (XG10)

Including the models, already supported in the TN011 legacy license:

• Corolla 2018+
• Camry 2018+
• Highlander 2018+
• Mirai 2020+

No additional subscriptions (dealer access) are required to complete the key programming procedure.

This solution covers said models, regardless of the market on which they are offered – all versions of the models are supported (US, European, UK, Asia). Smart system reset is NOT needed, nor a connection to Toyota servers.

Depending on the transponder type in the vehicle, either a HT-AES (TA64) or a DST-AES (TA68) emulator will be required. CB012 will also be required for internal CAN-BUS connection to the vehicle.
An AVDI interface with a valid AMS subscription, a ZN002 or ZN003 PROTAG V2 Programmer are required to use this license.

The TN015 is a step further in the development of key programming solutions for Toyota vehicles by ABRITES. Our team has created a license for a selection of vehicles, manufactured after 2020, equipped with a Denso Smart System with BA type DST-AES keys.

Functionalities:

• Spare key programming
• ALL KEYS LOST

Supported models:
Sienna 2020+ (XL40)
Harrier/Venza 2020+ (XU80)
Tundra 2021+ (XK70)
Land Cruiser 2021+ (J300)
RAV4 Facelift 2022+ (XA50)

Including the models, already supported by the TN012 legacy license:

• CH-R 2018+
• Prius 2018+
• Avalon 2018+
• RAV4 2018+

No additional subscriptions (dealer access) are required to complete the key programming procedure.

In order to perform the procedure, the TA68 DST-AES emulator is needed. CB012 will also be required for internal CAN-BUS connection to the vehicle.
An AVDI interface with a valid AMS subscription, a ZN002 or ZN003 PROTAG V2 Programmer are required to use this license.
The TN016 license provides a complete key programming software solution for the full range of Lexus vehicles, produced after 2018.
Even the latest 2022 RX and NX models with B9 DST-AES keys and Denso Smart System are supported.

Functionalities:

• ALL KEYS LOST key programming
• Spare key programming completely by OBDII

Supported models:

• RX 2022+
• NX 2021+
• RXL 2018+
• ES 2018+
• LS 2018+
• UX 2018+

Stable Internet connection and the ZN002 or ZN003 PROTAG Programmer, as well as the TA68 DST-AES transponder emulator and the CB012 cable set are needed to complete the procedures.

Please, refer to the Abrites Diagnostics for Toyota/Lexus/Scion User Manual for additional information on the procedures.
AVDI with an active AMS is needed to purchase and use this package
