Abrites TN014 – Key programming for 2020+ Toyota vehicles (BA HT-AES)

Abrites TN014 license expands the key programming capabilities of the ABRITES software for the latest generations Toyota vehicles, equipped with Tokai Rika Smart System with BA type HT-AES keys. Even the latest models 2022/2023 are supported! (see the list below)

Functionalities:

• Spare key programming
• ALL KEYS LOST

Supported models:

• Yaris 2020+ (XP210) BA HT-AES
• Yaris Cross 2021+ (XP210) BA HT-AES
• Corolla Facelift 2022+ (E210) BA HT-AES
• Corolla Cross Facelift 2022+ (XG10) BA HT-AES
• Aygo X 2022+
• Yaris GR 2021+
• Corolla GR 2022+

Including the models, already supported in the TN011 legacy license:

• Corolla 2018+ AA HT-AES
• Camry 2018+ A9 DST-AES
• Highlander 2018+ AA DST-AES
• Mirai 2020+ AA DST-AES

No additional subscriptions (dealer access) are required to complete the key programming procedure.

This solution covers said models, regardless of the market on which they are offered – all versions of the models are supported (US, European, UK, Asia). Smart system reset is NOT needed, nor a connection to Toyota servers.

Depending on the transponder type in the vehicle, either a HT-AES (TA64) or a DST-AES (TA68) emulator will be required. CB012 will also be required for internal CAN-BUS connection to the vehicle.
An AVDI interface with a valid AMS subscription, a ZN002 or ZN003 PROTAG V2 Programmer are required to use this license.
